Contactorul motorului CEM180E.22-500V-AC/DC 004646036
Disponibil
Specificatii
- Cod ETI:
- 004646036
- Descriere:
- CEM180E.22-500V-AC/DC
- Denumire clasă:
- Contactorul motorului
- Funcție:
- Contactor pentru motoare
- I (AC1) (A):
- 225A
- I (AC3 400V) (A):
- 180A
- Tensiunea nominala (V AC) :
- 1000V
- Tensiunea de control Uc (V AC) :
- 500V
- Tensiunea de control Uc (V DC) :
- 500V
- Număr de poli:
- 3
- Număr de contacte auxiliare NC:
- 2
Documente
Date logistica
Produse
- Greutatea produsului
- 0.295 kg
- Tarif vamal
- 85364900
- logis_net_width
- 136 mm
- logis_net_height
- 183 mm
- logis_net_depth
- 170 mm
ambalare pentru transport
- Cantitate
- 1
- EAN
- 7891327260702
- Greutate
- 5.025 kg
- Cantitate. transport
- 157
Clasificare ETIM
- Clasificare
- EC000066
- Denumire clasă
- Power contactor, AC switching
- Rated control supply voltage AC 50 Hz
- 500…500V
- Rated control supply voltage AC 60 Hz
- 500…500V
- Rated control supply voltage DC
- 500…500V
- Voltage type for actuating
- AC/DC
- Rated operation current Ie at AC-1, 400 V
- 225A
- Rated operation current Ie at AC-3, 400 V
- 180A
- Rated operation power at AC-3, 400 V
- 90kW
- Modular version
- Nu
- Number of auxiliary contacts as normally open contact
- 2
- Number of auxiliary contacts as normally closed contact
- 2
- Type of electrical connection of main circuit
- Rail connection
- Number of normally open contacts as main contact
- 3
CEM180E.22-500V-AC/DC
