Diferențial RCCB EFI-P2R B G/KV 40/0.03 002061002
Disponibil
La cerere
Va rugam solicitati informatii despre produs.
Specificatii
- Cod ETI:
- 002061002
- Descriere:
- EFI-P2R B G/KV 40/0.03
- Denumire clasă:
- Diferențial RCCB
- Curent de defect nominal (A):
- 0.03
- Tip curent:
- B
- Curent nominal (A):
- 40
- Tip:
- RCCB
- Număr de poli:
- 1p+N
- Curent nominal de scurtcircuit Inc (kA):
- 10 kA
- Timp de declansare :
- short time delayed
- Tensiunea nominală(V):
- 230
- Frecvență nominală (Hz):
- 50/60
- Secțiune transversală nominală:
- 1...50
- Standarde:
- EN/IEC 61008-1, IEC 62423
- Grad de protecție IP:
- IP20
- Tip montaj:
- TH 35
- Adâncime (mm):
- 70
Documente
Date logistica
Produse
- Tarif vamal
- 85362010
Ambalare de baza
- Cantitate
- 1
- EAN
- 3838400119957
- Greutate
- 0.23 kg
ambalare pentru transport
- Cantitate
- 54
- EAN
- 3838400119964
- Greutate
- 12.77 kg
- Cantitate. transport
- 2808
Clasificare ETIM
- Clasificare
- EC000003
- Denumire clasă
- Residual current circuit breaker (RCCB)
- Number of poles
- 2
- Rated voltage
- 230V
- Rated current
- 40A
- Rated fault current
- 30mA
- Rated insulation voltage Ui
- 253V
- Rated impulse withstand voltage Uimp
- 4kV
- Mounting method
- DIN rail
- Leakage current type
- B
- Selective protection
- Nu
- Short-time delayed tripping
- Da
- Short-circuit breaking capacity (Icw)
- 10kA
- Surge current capacity
- 3kA
- Frequency
- 50 Hz
- Additional equipment possible
- Nu
- With interlocking device
- Nu
- Degree of protection (IP)
- IP20
- Width in number of modular spacings
- 2
- Built-in depth
- 70mm
- Ambient temperature during operating
- -25...40°C
- Pollution degree
- 2
- Connectable conductor cross section multi-wired
- 1...35mm²
- Connectable conductor cross section solid-core
- 1...35mm²
EFI-P2R B G/KV 40/0.03
