NHU1XL gPV 50A/1500V DC UL Element fuzibil

Cod ETI:: 004110623
Tip:: NH-U
Mărime:: NH1XL
Curent nominal:: 50 A
Caracteristici:: gPV
Indicator:: Indicator principal al siguranței
Tensiune nominală DC:: 1500 V
Capacitatea de rupere DC:: 30 kA
L/R:: 3 ms
Disiparea puterii (0,7xIn):: 6 W
Putere disipată:: 14 W
Curentul de pre-arc (A2s):: 800
Operare Joule integrală (A2s):: 3.500
Certificat UL:: E347771
Standarde:: IEC 60269-6, UL 248-19
Aplicație:: Fuse link for DC application

Accesorii

Produs

Greutate: 950 g
Net width: 51 mm
Net height: 198 mm
Net depth: 51 mm
Stock unit of measure: pcs

Ambalare de bază

Basic packaging quantity: 1 pcs
EAN code for a basic packaging: 3838895737070
Basic packaging weight: 0,95 kg
Basic Packaging Dimensions Height: 0,055 m
Basic Packaging Dimensions Width: 0,205 m
Basic Packaging Dimensions Depth: 0,076 m
Basic packaging volume: 0,001 m³

Ambalare transport

Transport packaging quantity: 16 pcs
EAN code for a transport packaging: 3838895737087
Transport packaging weight: 15,55 kg
Transport Packaging Dimensions Height: 0,255 m
Transport Packaging Dimensions Width: 0,295 m
Transport Packaging Dimensions Depth: 0,235 m
Transport packaging volume: 0,018 m³
Pallet quantity: 832 pcs
Customs tariff: 85351000

Voltage type: DC
Fuse construction type according to IEC 60269: 1XL
Power loss at rated current: 14 W
Rated switching capacity DC: 30 kA
Type of fuse status indicator: Top fuse status indicator
Rated current: 50 A
Rated voltage DC: 1.500
Utilization category: gPV (photovoltaic protection)
